Window Plan & Elevation AutoCAD Pack (Free DWG)
Align your plans and elevations perfectly.
This pack includes essential window blocks in both view types, featuring Wipeouts to automatically hide wall lines underneath for cleaner drafting.
$0.00
Product Overview
Stop trimming lines every time you move a window. This professional AutoCAD Window Block pack provides accurate, masking-enabled window symbols ready to drag and drop. Includes matching plan and elevation views for consistency in your documentation.
What’s Inside the Pack?
- File Format: .DWG (2013+ Compatible)
- Layers: Pre-assigned standard architectural layers
- Content: A variety of Window Blocks including Casement, Sliding, and Fixed windows in Plan and Elevation.
Why Use aLBE Studio Blocks?
- ✅ Wipeout Enabled: Automatically masks wall lines below the block.
- ✅ Coordinated Views: Plan and elevation blocks match perfectly.
- ✅ Standardized: Represents standard frame and glass thicknesses.
Pro Tip: Ensure “Wipeout Frames” are turned off in your drawing settings so the masking works without showing the boundary line.
