North Arrows & Scale Bars AutoCAD Pack (Free DWG)
Orientation is everything.
Don’t use ugly, unscaled symbols. This pack includes professional North Arrows and Scale Bars (Graphical & Text) to ensure your plans are readable and properly oriented.
$0.00
Product Overview
Stop drawing custom arrows for every project. This professional AutoCAD General Icon pack provides accurate, standard-compliant symbols ready to drag and drop into your drawings. Includes modern, minimal, and classic styles to fit your presentation aesthetic.
What’s Inside the Pack?
- File Format: .DWG (2013+ Compatible)
- Layers: Pre-assigned standard architectural layers
- Content: A variety of General Icons including North Arrows, Graphical Scale Bars, and Section/Elevation Markers.
Why Use aLBE Studio Blocks?
- ✅ Annotative Ready: Symbols automatically size themselves to the viewport scale.
- ✅ Dynamic Rotation: Rotate North Arrows without breaking text alignment.
- ✅ Standardized: Professional graphic styles suitable for construction docs.
Pro Tip: Use the Graphical Scale Bar instead of text so the scale remains accurate even if the drawing is printed at a reduced size.
